Alarm Kit - VISTA20P/6160RFKT1
Kit Includes:
- 1 - Honeywell VISTA®20P Control Panel - 357-VISTA20P
- 1 - Honeywell 6160RF Integrated Keypad and Receiver - 357-6160RF
- 1 - 12V4.0AH LEAD ACID RECHARG BAT - NT-12/4
- 1 - Honeywell WAVE2 Two-tone Siren - 357-WAVE2
Honeywell VISTA®20P Control Panel - 357-VISTA20P
The high capacity, feature-rich VISTA-20P lets you deliver more value to your customers on each and every sale with up to 48 zones of protection, Internet uploading/downloading, graphic keypad support and dual partitions. VISTA-20P gives you the ability to send alarm signals and upload/download via an Internet Protocol (IP), improving the speed at which information can be delivered to and from the control panel. In addition, the VISTA-20P, used with an AlarmNet® Internet or 4G communicator can be installed in premises without TELCO lines. The panel’s installation advantages, innovative end-user benefits and robust system capacity make the value-priced VISTA-20P an ideal choice for higher end installations.
Features:
- IP alarm reporting and uploading/ downloading capability for Internet and Intranet use via iGSMV4G, 7845i-ENT, GSMV4G or GSMX4G
- Supports four graphic touchscreen keypads
- Wireless keys can be programmed without using zones
- Eight on-board hardwired zones standard (15 when Zone Doubling feature is used)
- 40 hardwire expansion zones
- 40 wireless expansion zones
- Two low current on-board trigger outputs
- 100 Event Log viewable at system keypads with time/date stamp
- 48 system user codes assignable to either partition
- Expandable to 48 total zones when used with hardwired and/or wireless expansion modules
- Two independent partitions plus a common partition
- Global Arming from any system keypad
- Go to function to view or operate one partition from the other
- Separate partition account numbers
- 16 output devices
- Relays (Model 4204 Relay Modules, or 4229 Expansion Module)
- Four installer-configurable zone types allows the installer to create custom zone types by assigning all zone attributes
- Supports four-wire and up to 16 two-wire smokes
- Works with Sentrol CleanMe™ maintenance signal
- Multiple actions on output devices depending on system state
- Turns lights off when system arms
- Turns the same light on when system disarms
- Flashes same lights when system is in alarm
- Built-in phone line cut monitor with programmable delay and annunciation options
- Display on system keypads
- Trigger local sounders
- Trigger system bell
- Security Dealer Features
- Automatic System Load Shed
- During extended AC power fail, the system battery will be disconnected to prevent irreversible battery failure. Reduces service calls to replace batteries.
- Dynamic Signaling
- Reduces redundant reporting to the central station when multiple reporting methods are used; i.e. digital dialer and AlarmNet radio
- Valuable End-User Features
- Viewable on system keypads:
- Exit countdown
- Time and date display*
- Event log*
- Auto keypad backlighting on entry
- Keyswitch arming
- Programmable macro buttons and single-button arming
- Supports a variety of wireless remote controls for single-button operation
- User Scheduling
- Latchkey reports to pagers
- Auto arm/disarm
- “User access” time windows
- VIP Module allows system control from any touchtone phone
- Chime by zone
*Requires custom alpha keypad
Literature:
Honeywell 6160RF Integrated Keypad and Receiver - 357-6160RF
The 6160RF’s integrated keypad and receiver design helps reduce installation, material and inventory costs while increasing valuable add-on opportunities. It adds full wireless capability to any VISTA control without additional wiring or sacrificing zones and can help close sales by easily adding 5804, 5804BDV or 5878 wireless interfaces for end-user remote convenience.
Dealers can add the 5828 and 5828V wireless keypads to VISTA for the first time, presenting a tremendous upsell opportunity by letting them offer their customers secondary wireless keypads on every installation with virtually no install time.
Features:
- 6160 Custom Alpha Keypad
- Built in 5881ENH unlimited zone wireless receiver
- Compatible with 5828/5828V wireless keypads on VISTA systems*
- Single four-wire run is all that’s required
- It is the ideal choice where wireless keys are to be used:
- Keys can be programmed at the panel, just as they would with the 5881ENH
- Fully compatible with all 5800 wireless devices including bidirectional devices*
- The 5800TM Module needed to support the 5804BD and 5804BDV is already built-in
- Supports encrypted operation of the 5804E and 5804BDV four-button keys
- Easy to Operate
- The custom alpha display is easy to read, with large characters and simplified descriptions
- The sounder beeps to help identify security system status
- Comfortable soft-touch keys labeled with simple commands are illuminated for nighttime visibility
- Four larger function keys can be programmed for one touch operation and are accessible even when the door is closed
- Stylishly Designed
- Sleek, white design blends with any décor
- Contoured, removable door lets customers customize the keypad for the look they want
- With the door closed the keypad has a smooth, unobtrusive appearance
*Not compatible with 5839
Literature:
12V4.0AH LEAD ACID RECHARG BAT - NT-12/4
Features:
- Application/Usage: Security Device
- Battery Rechargeable: Yes
- Battery Size: Proprietary Battery Size
- Battery Chemistry: Lead Acid
- Battery Capacity: 4000 mAh
- Output Voltage: 12 V DC
- Maximum Battery Run Time: 12 Hour
Honeywell WAVE2 Two-tone Siren - 357-WAVE2
The Wave's unique snap-open HINGED CASE DESIGN- an industry first for sounders - allows for installation without disassembly
The Wave-F speaker and Wave 2F siren can be RECESSED in a standard double gang electrical box
TERMINAL STRIP - no soldering or splicing required
Features:
- Patented case design fits single gang electrical box or wall plate
- Snap-open hinged case cover for faster installation
- Louder (106db) dual tone siren output
- Terminal strip eliminates splicing and soldering
- Corner or ceiling mounting with no additional brackets or hardware
- Channeled case back for convenient wiring access
- Vertical or horizontal mounting for great versatility
Literature:
